Screw diameter mm
Screw length L/D
Screw speed rpm
Bearing axial dynamic load daN
30
24
100
18700
30
28
100
18700
other on request up to 150
N° of barrel heating zones
Heating power of each barrel zone W
Max. working temperature °C
Max. working pressure BAR
N° of barrel cooling zones
Cooling zones power of the barrel W
Type of cooling of the barrel
3
1200
350
1000
3
12
air
4
800
350
1000
4
12
air
other
other
450
other
Hopper capacity litres
9
9
35
N° of cooling zones of the feeding zone
Type of cooling
Water comsumption m3/h
2
water
~0.2
2
water
~0.2
Motor type
Motor KW
N° of revolution rpm
Power of motor fan W
A.C.
5.5
1450
46
A.C.
5.5
1450
46
D.C. - Brushless
different
Reduction gear type
Reduction gear ratio I=
Reduction gear nominal torque daNm
epicycloidal
14
90
epicycloidal
14
90
Parallel axis
other on request
Total installed power KW
Extruder weight Kgs
8.6
130
9.6
135
NOTE: Specifications refer to standard extruders only. On request we can supply machines with different technical features, according to materials to be processed. Non binding data, the manufacturer can introduce without notice any modification considered as necessary.
